MEYLE PULL ROPE EMERGENCY SWITCH NSR 03

• These switches must be used in control current circuits only

• They serve as devices to prevent incidents, injuries and damages to production assets

• Pull rope mounted on both sides of the activation lever a line length of about

100 m (max. 150 m) can be monitored

• The switch will be activated automatically by pre-loading via pull springs in case of a rope rupture on one side

• If the pull rope emergency switch is triggered with an inadmissible high trigger force (>80kg) the mechanism is locked and can not be unlocked

Applications

Conveyor belts in the iron & steel industry, mineral exploitation industry, loading & unloading facilities, chemical industry and mining
