DOLD EMERGENCY STOP MODULE LG5925.48/61

• According to

-- Performance Level (PL) e and category 4 to EN ISO 13849-1

-- SIL Claimed Level (SIL CL) 3 to IEC/EN 62061

-- Safety Integrity Level (SIL) 3 to IEC/EN 61508 and IEC/EN 61511

• According to EN 50156-2 for furnaces

• Output: max. 4 NO contacts, see contacts

• LG 5925.54: 1 semiconductor output

• Single and 2-channel operation

• Line fault detection on On-button

• Manual restart or automatic restart, switch S2

• With or without cross fault monitoring in the E-stop loop, switch S1

• LG 5925.54: with cross fault monitoring in the E-stop loop

• LED indicator for state of operation

• LED indicator for channel 1 and 2

• Removable terminal strips

• Wire connection: also 2 x 1.5 mm2 stranded ferruled, or

2 x 2.5 mm2 solid DIN 46228-1/-2/-3/-4

• As option with pluggable terminal blocks for easy exchange

of devices

-- with screw terminals

-- or with cage clamp terminals

• Width: 22.5 mm
