WAYCON ENCODER SX50-1000-1R-SA12-VG1

Features :

• High quality draw wire position sensors for industrial use

• Measurement ranges 50 mm up to 1250 mm

• Analog Output: Potentiometer, 0...10 V, 4...20 mA

• Teachable Outputs: 0...5 V, 0...10 V, with an additional Open-Collector switching output

• Digital Output Incremental: RS422 (TTL), Push-Pull

• Digital Output Absolute: CANopen, SSI

• Linearity up to ±0.02% of full scale

• Protection class up to IP67

• Temperature range: -20...+85 °C (optional -40 °C or +120 °C)

• High dynamics

• High interference immunity factor
