HONEYWELL LIMIT SWITCH GLCB01A9A

• Designed to EN50047 standard

• Metal housing or double-insulated plastic housing for indoor and outdoor applications

• Wide range of actuator heads and levers

• Heads can be positioned at 90° increments for design flexibility. Side rotary actuator heads can be factory set for CW, CCW, or CW and CCW actuation

• Certified for global applications: CE, UL, CSA, CCC1

• Conforms to CE, EN50047, IEC/EN 60947-5-1; CSA C22.2 #14; UL 508; CCC1 GB14048.5, EN45545-2 (GLC/GLE)

• Sealed to IP66 and NEMA/UL 1, 4, 12, and 13

• -40 °C [-40 °F] standard construction for side rotary and plunger actuated switches suitable for many severe outdoor environments

• Dual bearing design on side rotary actuators reduces side loading and enhances mechanical life

• Variety of NC and NO double-break snap-action or slowaction contact options

• Silver contacts for power switching or gold-plated contacts for low energy loads

• Normally closed contacts are positive opening , and conform to EN/IEC 60947-5-1-3 to provide forced opening of the normally closed contact. Each contact throw is electrically isolated to accept different voltages (Form Zb contacts).

Double pole double throw (2NC/2NO) contact option require same polarity for each pole. (Form Za for each pole)

• Contact blocks are available as snap action or slow action

• Mechanical life up to 10 million operations

Application

• Passenger elevators

• Commerical appliances

• Escalators/moving stairs

• Scissor/platform lifts

• Material handling

• Machine tool equipment

• Off-road equipment
