DRUCK PRESSURE GAUGE DPI 104 200 bar

• 0.05% full scale (FS) accuracy

• Pressure ranges to 1400 bar (20,000 psi)

• Eleven selectable pressure units

• Large, easy-to-read display with five-digit resolution

• % pressure indication and additional bar graph for quick visual reference

• Temperature compensated accuracy from -10°C to 50°C (14°F to 122°F)

• 0 to 5V analog output

• Pressure switch test

• Minimum/maximum, tare and alarm functions

• IDOS compatible and RS232 serial interface

• Hazardous Area (Intrinsically safe) version available

• Stainless steel or Inconel pressure cavity for aggressive media

Application

• Process monitoring and control

• Test and calibration
