KANSAI LEVEL SWITCH NM-8B

A rotating paddle, being loaded by sediments in a tank, activates a limit switch and brings contact output and motor rotation to a halt at the same time. With no load by sediments, the motor resumes rotation. When the paddle is overloaded or suffers strong shock, a clutch system prevents the motor from being broken by letting out excessive load and shock.

●Cost effective, standard type with no excessive functions.

●Flange size: JIS5K65A equivalent

●Flange of non-standard size can be manufactured (Over JIS5K65A).

●Screwed joint (G1B) with the flange taken off.

●Weight: about 1.65kg
